Specifications
| Model | CH-GD-S6086 | |
| Electronical | Rated Input： | 220-240VAC |
| work Range | 165VAC-265VAC | |
| Frequency： | 50Hz/60Hz | |
| System Power： | 36W | |
| Driver Brand | KGP | |
| PFC | PF>0.5 | |
| Lumination | LED Chip Model | Epistar COB |
| CRI | > 90 | |
| System Lumen | 3600lms | |
| Efficiency of Fixture | 100lm/w | |
| Emitting color: | warm whtie, natural whtie, day light | |
| Color Temperature： | 2700K, 3000K, 4000K，5000K , 6000K | |
| Optical | Beam Angle | 15° 24° 38° 60° |
| Device | PMMA Lens | |
| Control Method |
ON/OFF Dali, Triac dim |
|
| Classification of Protection: | Class II | |
| Structure | Housing Material： | Diecast Aluminum |
| Color: | Sandy white / Sandy Black | |
| Heatsink Size: | Ø95x120mm | |
| Adapter | 4wires | |
| Warranty: | 3Years | |
| Package: | Print Color Box or Blank Brown Box | |
