Specifications
|
Model no. |
TH-TL-60-206-30 |
TH-TL-45-412-55 |
|
Power |
30W | 50W |
|
Driver Brand |
Intrack Flicker free,pf0.9 |
Intrack Flicker free,pf0.9 |
| Adapter |
1PHASE 2/3 wires |
1PHASE 2/3 wires |
|
Input Voltage |
170-265VAC |
170-265VAC |
|
LED Chip |
SMD | SMD |
|
CRI |
≥80 90 |
≥80 90 |
|
Efficiency |
170lm/w |
170lm/w |
| Beam | 90° |
90° |
| CCT | 3000K,4000K,6000K or 3CCT |
3000K,4000K,6000K or 3CCT |
|
Heatsink Materials |
Diecast Aluminum |
Diecast Aluminum |
|
Heatsink Color |
White/Black |
White/Black |
|
Heatsink Size |
L600*W60*H55mm |
L1190*W60*H55mm |
| Cetification | CE RoHS ERP |
CE RoHS ERP |
